This guide explains how to build Giac on Windows using MSYS2 with the CLANG64 environment. Both 64-bit and 32-bit builds are supported.

​
Prerequisites

​
Install MSYS2

1

Download MSYS2

Download the installer from msys2.org and run it.
2

Update package database

After installation, open the MSYS2 terminal and update the package database:
pacman -Syu
Close and reopen the terminal, then run:
pacman -Su
3

Launch CLANG64 environment

From the Start menu, launch MSYS2 CLANG64 (not MINGW64 or UCRT64).

​
Install Required Packages

For 64-bit builds (CLANG64), install the following packages:
pacman -S base-devel \
          mingw-w64-clang-x86_64-cc \
          mingw-w64-clang-x86_64-gmp \
          mingw-w64-clang-x86_64-mpfr \
          mingw-w64-clang-x86_64-cmake \
          mingw-w64-clang-x86_64-make
The prebuilt source tree includes static versions of GMP and MPFR for Windows (clang64 and clang32). You can skip installing mingw-w64-clang-x86_64-gmp and mingw-w64-clang-x86_64-mpfr if using the defaults.

​
For 32-bit Builds

Use the CLANG32 flavor instead, and replace x86_64 with i686:
CLANG32 Packages
pacman -S base-devel \
          mingw-w64-clang-i686-cc \
          mingw-w64-clang-i686-gmp \
          mingw-w64-clang-i686-mpfr \
          mingw-w64-clang-i686-cmake \
          mingw-w64-clang-i686-make

​
Building with CMake

1

Open CLANG64 terminal

Launch MSYS2 CLANG64 from the Start menu.
2

Navigate to source directory

cd /path/to/giac
3

Create build directory

mkdir build
cd build
4

Configure with CMake

CC=clang CXX=clang++ cmake -G "MinGW Makefiles" ..
This configures the build to:
  • Use Clang compiler
  • Generate MinGW-compatible Makefiles
  • Use prebuilt static libraries from src/jni/prebuilt/windows/clang64/
5

Compile

mingw32-make
This builds:
  • minigiac.exe: Command-line executable
  • javagiac.dll: Dynamic library for JNI integration
6

Run the executable

./minigiac.exe

​
Windows-Specific Configuration

​
Preprocessor Definitions

The Windows build uses these specific definitions:
DefinitionPurpose
GIAC_MPQSEnable MPQS factorization algorithm
__MINGW_HMark as MinGW build
MINGW32MinGW compatibility
HAVE_NO_SYS_TIMES_Hsys/times.h not available
HAVE_NO_SYS_RESOURCE_WAIT_Hsys/resource.h not available
HAVE_NO_PWD_Hpwd.h not available
HAVE_NO_CWDNo current working directory
NO_CLOCKDisable clock functions
usleep=Undefine usleep (not available)
YY_NO_UNISTD_HDon’t use unistd.h in lexer

​
Compiler Flags

-fpermissive        # Allow some non-conforming code
-std=c++0x          # C++11 support

​
Linker Configuration

The Windows build uses static linking to minimize dependencies:
-Wl,--add-stdcall-alias    # Add stdcall aliases for exports
-s                          # Strip symbols
-static-libgcc              # Link libgcc statically
-static-libstdc++           # Link libstdc++ statically
This creates a self-contained executable with no external DLL dependencies.

​
Building JNI Library

The JNI library (javagiac.dll) is built with a module definition file:
# The giac.def file is located at:
src/jni/giac.def
Build specifically for JNI:
mingw32-make javagiac
The output will be:
build/libjavagiac.dll

​
Building with Gradle

Windows builds are supported through Gradle when using MSYS2:
1

Set up environment

Ensure you’re in the CLANG64 environment and have all prerequisites installed.
2

Build Windows 64-bit library

../gradlew javagiacWin64SharedLibrary
3

Output location

The library will be built at:
build/libs/javagiac/shared/win64/javagiac.dll

​
Static vs Dynamic Linking

​
Static Linking (Default)

The default configuration uses static linking for all dependencies:
target_link_libraries(minigiac ${MPFR_STATIC} ${GMP_STATIC})
Benefits:
  • Single executable, no DLL dependencies
  • Better portability
  • No version conflicts
Drawback:
  • Larger executable size

​
Dynamic Linking

To use dynamic linking instead, modify CMakeLists.txt:
# Line 262, change from:
target_link_libraries(minigiac ${MPFR_STATIC} ${GMP_STATIC})

# To:
target_link_libraries(minigiac mpfr gmp)
Then ensure the DLLs are in your PATH or the same directory as the executable.

​
Environment Detection

CMake automatically detects your MSYS2 environment:
if("$ENV{MSYSTEM}" STREQUAL "CLANG64")
    message(STATUS "Using prebuilt gmp/mpfr for clang64")
    # Uses src/jni/prebuilt/windows/clang64/
endif()

if("$ENV{MSYSTEM}" STREQUAL "CLANG32")
    message(STATUS "Using prebuilt gmp/mpfr for clang32")
    # Uses src/jni/prebuilt/windows/clang32/
endif()

​
Troubleshooting

​
Wrong MSYS2 Environment

Error:
CMake Error: CMAKE_C_COMPILER not set
Solution: Ensure you’re using MSYS2 CLANG64 (or CLANG32), not MINGW64 or MSYS2.

​
Missing Compiler

Error:
The C compiler "clang" is not able to compile a simple test program
Solution: Install the Clang compiler:
pacman -S mingw-w64-clang-x86_64-cc

​
Library Not Found

Error:
Unable to find library gmp in src/jni/prebuilt/windows/clang64/
Solution: Verify the prebuilt directory structure:
ls src/jni/prebuilt/windows/clang64/
# Should contain: libgmp.a, libmpfr.a
If missing, install system libraries:
pacman -S mingw-w64-clang-x86_64-gmp mingw-w64-clang-x86_64-mpfr

​
CMake Generator Issues

Error:
CMake Error: Could not create named generator MinGW Makefiles
Solution: Install mingw32-make:
pacman -S mingw-w64-clang-x86_64-make

​
Permission Denied Errors

Error:
bash: ./minigiac.exe: Permission denied
Solution: The file might be locked by antivirus. Try:
chmod +x minigiac.exe
./minigiac.exe
Or run from Windows Command Prompt:
minigiac.exe

​
Missing DLL Errors (Dynamic Build)

Error when running:
The code execution cannot proceed because libgmp-10.dll was not found
Solution: Either:
  1. Copy required DLLs to the executable directory
  2. Add MSYS2 bin directory to PATH:
    export PATH="/clang64/bin:$PATH"
  3. Use static linking (default configuration)

​
32-bit Build Instructions

For 32-bit builds, use CLANG32 flavor:
1

Launch CLANG32 environment

Open MSYS2 CLANG32 from Start menu.
2

Install 32-bit packages

pacman -S mingw-w64-clang-i686-cc \
          mingw-w64-clang-i686-cmake \
          mingw-w64-clang-i686-make
3

Build with CMake

mkdir build
cd build
CC=clang CXX=clang++ cmake -G "MinGW Makefiles" ..
mingw32-make
CMake will automatically detect CLANG32 and use libraries from src/jni/prebuilt/windows/clang32/.

​
Visual Studio Support

The current build system is optimized for MSYS2/Clang. Visual Studio support is limited. For Visual Studio builds, additional configuration would be required.
The build.gradle file includes a Visual Studio plugin, but it’s primarily used for cross-platform development. For pure Windows development, MSYS2 with Clang is the recommended approach.

​
Building for Distribution

For release builds:
CC=clang CXX=clang++ cmake -DCMAKE_BUILD_TYPE=Release -G "MinGW Makefiles" ..
mingw32-make
This enables optimizations and produces smaller binaries.

​
Testing the Build

Run basic tests:
# Interactive mode
./minigiac.exe

# Test with expression
echo "factor(x^2-1)" | ./minigiac.exe
Expected output:
(x-1)*(x+1)
