Graph Node provides built-in aggregation capabilities for timeseries data, enabling efficient storage and querying of metrics, statistics, and time-bucketed analytics. This feature is available from spec version 1.1.0 onwards.

​
Overview

Aggregations are declared in your subgraph schema through two complementary types:
  1. Timeseries type: Stores raw data points with timestamps
  2. Aggregation type: Defines how raw data is aggregated over time intervals
Graph Node automatically computes and maintains aggregations as new data arrives, rolling up statistics for hourly and daily intervals.

​
Defining Timeseries

A timeseries entity stores individual data points with automatic timestamps:
type Data @entity(timeseries: true) {
  id: Int8!
  timestamp: Timestamp!
  price: BigDecimal!
  volume: BigDecimal!
}
​
@entity(timeseries: true)
required
Marks the type as a timeseries. These entities are immutable and append-only.
​
id
Int8!
required
Automatically set by Graph Node in insertion order. Must be of type Int8.
​
timestamp
Timestamp!
required
Automatically set by Graph Node to the current block timestamp. User-provided values are silently overridden.

​
Timeseries Characteristics

  • Immutable: Once created, timeseries entities cannot be updated or deleted
  • Automatic IDs: The id field is set automatically in ascending order
  • Automatic timestamps: The timestamp field is always set to block timestamp
  • Efficient storage: Optimized for append-only operations

​
Defining Aggregations

Aggregations compute statistics over timeseries data at specified time intervals:
type Stats @aggregation(intervals: ["hour", "day"], source: "Data") {
  id: Int8!
  timestamp: Timestamp!
  sum: BigDecimal! @aggregate(fn: "sum", arg: "price")
  avg: BigDecimal! @aggregate(fn: "avg", arg: "price")
  max: BigDecimal! @aggregate(fn: "max", arg: "price")
  count: Int8! @aggregate(fn: "count")
}
​
@aggregation
required
Marks the type as an aggregation with two required arguments:
  • intervals: Array of time intervals ("hour" or "day")
  • source: Name of the timeseries type to aggregate
​
id
Int8!
required
Automatically set by Graph Node. Set to the id of one of the source data points (unspecified which).
​
timestamp
Timestamp!
required
Automatically set to the beginning of the aggregation time interval.

​
Aggregation Functions

The @aggregate directive supports these functions:
sum: BigDecimal! @aggregate(fn: "sum", arg: "price")
​
sum
Aggregation Function
Sum of all values in the interval.
​
count
Aggregation Function
Number of data points in the interval.
​
min
Aggregation Function
Minimum value in the interval.
​
max
Aggregation Function
Maximum value in the interval.
​
first
Aggregation Function
First value in the interval (by timeseries id ordering).
​
last
Aggregation Function
Last value in the interval (by timeseries id ordering).

​
Dimensions

Dimensions are non-aggregated fields used to group data. They enable multi-dimensional aggregations:
type Token @entity {
  id: ID!
  symbol: String!
  decimals: Int!
}

type TokenData @entity(timeseries: true) {
  id: Int8!
  timestamp: Timestamp!
  token: Token!  # Dimension
  price: BigDecimal!
  volume: BigDecimal!
}

type TokenStats @aggregation(intervals: ["hour", "day"], source: "TokenData") {
  id: Int8!
  timestamp: Timestamp!
  token: Token!  # Dimension - groups by token
  totalVolume: BigDecimal! @aggregate(fn: "sum", arg: "volume")
  avgPrice: BigDecimal! @aggregate(fn: "avg", arg: "price")
  count: Int8! @aggregate(fn: "count")
}
How dimensions work:
  • Fields without @aggregate are dimensions
  • Each unique combination of dimension values creates a separate aggregation series
  • In the example above, each token gets its own hourly and daily statistics

​
Cumulative Aggregations

By default, aggregations compute values for each time interval independently. Cumulative aggregations compute running totals across all intervals:
type TokenStats @aggregation(intervals: ["hour", "day"], source: "TokenData") {
  id: Int8!
  timestamp: Timestamp!
  token: Token!

  # Non-cumulative: volume for this hour/day only
  intervalVolume: BigDecimal! @aggregate(fn: "sum", arg: "volume")

  # Cumulative: total volume from beginning of time
  cumulativeVolume: BigDecimal! @aggregate(fn: "sum", arg: "volume", cumulative: true)

  # Cumulative count
  totalTransactions: Int8! @aggregate(fn: "count", cumulative: true)
}
​
cumulative
Boolean
default:"false"
When true, aggregates over the entire timeseries up to the end of the current interval.

​
Aggregation Expressions

The arg parameter can be a field name or a SQL expression:
type SwapData @entity(timeseries: true) {
  id: Int8!
  timestamp: Timestamp!
  amount0: BigDecimal!
  amount1: BigDecimal!
  priceUSD: BigDecimal!
}

type SwapStats @aggregation(intervals: ["hour", "day"], source: "SwapData") {
  id: Int8!
  timestamp: Timestamp!

  # Calculate total USD value
  totalValueUSD: BigDecimal! @aggregate(
    fn: "sum",
    arg: "amount0 * priceUSD"
  )

  # Maximum of two amounts
  maxAmount: BigDecimal! @aggregate(
    fn: "max",
    arg: "greatest(amount0, amount1)"
  )

  # Conditional aggregation
  largeSwapsCount: Int8! @aggregate(
    fn: "count",
    arg: "case when amount0 > 1000 then 1 else 0 end"
  )
}

​
Supported Expression Syntax

Expressions use SQL syntax with these supported features:
  • Arithmetic: +, -, *, /, %, ^
  • Comparison: =, !=, <, <=, >, >=
  • Logical: and, or, not
  • Other: is [not] {null|true|false}, is [not] distinct from
  • abs(x): Absolute value
  • ceil(x), ceiling(x): Round up
  • floor(x): Round down
  • div(x, y): Integer division
  • mod(x, y): Modulo
  • power(x, y): Exponentiation
  • gcd(x, y): Greatest common divisor
  • lcm(x, y): Least common multiple
  • sign(x): Sign (-1, 0, or 1)
  • coalesce(x, y, ...): First non-null value
  • nullif(x, y): NULL if x equals y
  • greatest(x, y, ...): Maximum value
  • least(x, y, ...): Minimum value
  • case when ... then ... else ... end: Conditional expression

​
Querying Aggregations

Graph Node creates top-level query fields for each aggregation:

​
Basic Aggregation Query

query {
  tokenStats(
    interval: "hour"
    first: 24
  ) {
    id
    timestamp
    totalVolume
    avgPrice
    count
  }
}
​
interval
Enum
required
Time interval to query: "hour" or "day" (must match intervals defined in schema).
​
current
Enum
default:"exclude"
Whether to include the current, partially filled bucket:
  • exclude: Only return completed, rolled-up buckets (default)
  • include: Also return in-progress bucket computed on-the-fly

​
Filtering Aggregations

Filter by dimensions and timestamp ranges:
query {
  tokenStats(
    interval: "hour"
    where: {
      token: "0x1234567890123456789012345678901234567890"
      timestamp_gte: "1704067200000000"
      timestamp_lt: "1704153600000000"
    }
    first: 24
  ) {
    timestamp
    token {
      symbol
    }
    totalVolume
    avgPrice
  }
}

​
Available Timestamp Filters

​
timestamp_eq
String
Exact timestamp match (microseconds since epoch).
​
timestamp_gte
String
Greater than or equal to timestamp.
​
timestamp_gt
String
Greater than timestamp.
​
timestamp_lte
String
Less than or equal to timestamp.
​
timestamp_lt
String
Less than timestamp.
​
timestamp_in
[String]
Timestamp in list.
Timestamps are strings containing microseconds since Unix epoch.Example: "1704164640000000" = 2024-01-02T03:04:00ZConvert from seconds: seconds * 1000000

​
Current Bucket

By default, aggregation queries return only completed, rolled-up buckets. Setting current: include adds the in-progress bucket:
query {
  tokenStats(
    interval: "hour"
    current: exclude
  ) {
    timestamp
    totalVolume
  }
}
How it works:
  • exclude: Only returns buckets whose time interval has ended and been rolled up
  • include: Adds one additional bucket computed on-the-fly from unrolled source data
  • The current bucket covers from the last completed bucket to the most recent data point

​
Nested Aggregation Queries

The current argument works on nested aggregation fields:
query {
  tokens {
    id
    symbol
    stats(interval: "hour", current: include) {
      timestamp
      totalVolume
      avgPrice
    }
  }
}
Current bucket support for nested fields is only available when the field references a single aggregation type. It’s not supported for aggregations accessed through interfaces with multiple implementations.

​
Complete Example

Here’s a comprehensive example showing timeseries and aggregations for DEX trading data:
schema.graphql
type Token @entity {
  id: ID!
  symbol: String!
  decimals: Int!
  stats: [TokenStats!]! @derivedFrom(field: "token")
}

type Pair @entity {
  id: ID!
  token0: Token!
  token1: Token!
  stats: [PairStats!]! @derivedFrom(field: "pair")
}

# Raw swap events
type SwapData @entity(timeseries: true) {
  id: Int8!
  timestamp: Timestamp!
  pair: Pair!
  amount0: BigDecimal!
  amount1: BigDecimal!
  amountUSD: BigDecimal!
}

# Aggregated pair statistics
type PairStats @aggregation(intervals: ["hour", "day"], source: "SwapData") {
  id: Int8!
  timestamp: Timestamp!
  pair: Pair!

  # Interval statistics
  volumeUSD: BigDecimal! @aggregate(fn: "sum", arg: "amountUSD")
  swapCount: Int8! @aggregate(fn: "count")

  # Price tracking
  openPrice: BigDecimal! @aggregate(fn: "first", arg: "amount1 / amount0")
  closePrice: BigDecimal! @aggregate(fn: "last", arg: "amount1 / amount0")
  highPrice: BigDecimal! @aggregate(fn: "max", arg: "amount1 / amount0")
  lowPrice: BigDecimal! @aggregate(fn: "min", arg: "amount1 / amount0")

  # Cumulative metrics
  cumulativeVolumeUSD: BigDecimal! @aggregate(
    fn: "sum",
    arg: "amountUSD",
    cumulative: true
  )
  totalSwaps: Int8! @aggregate(fn: "count", cumulative: true)
}

​
Query Examples

query {
  pairStats(
    interval: "hour"
    first: 24
    orderBy: timestamp
    orderDirection: desc
  ) {
    timestamp
    pair {
      token0 { symbol }
      token1 { symbol }
    }
    volumeUSD
    swapCount
    closePrice
  }
}

​
Sorting Behavior

Aggregations have a default sort order:
  • Sorted by timestamp and id in descending order by default
  • Returns most recent buckets first
  • Can be overridden with orderBy and orderDirection
# Default: Most recent first
query {
  tokenStats(interval: "hour") {
    timestamp
    totalVolume
  }
}

# Override: Oldest first
query {
  tokenStats(
    interval: "hour"
    orderBy: timestamp
    orderDirection: asc
  ) {
    timestamp
    totalVolume
  }
}

​
Best Practices

  1. Choose appropriate intervals: Use hourly for recent data, daily for historical trends
  2. Use dimensions wisely: Each dimension combination creates separate aggregation series
  3. Leverage cumulative aggregations: Useful for running totals and lifetime metrics
  4. Filter by timestamp: Always specify timestamp ranges to limit data scanned
  5. Monitor aggregation lag: Current buckets may not reflect all recent data until rollup completes
  6. Use expressions for computed metrics: Calculate derived values at aggregation time

​
