Architecture Overview

The Enterprise SOC Architecture is designed as a multi-layered system where each layer provides specific security capabilities. This overview explains the architectural structure, component integration, and data flows that enable comprehensive security operations.

​
Architecture Diagram

Enterprise SOC Architecture Diagram
Components highlighted in yellow represent long-term planned features that will be implemented in future phases.

​
Architectural Layers

The SOC architecture is organized into distinct functional layers that work together to provide end-to-end security operations:

Detection Layer

Network-based intrusion detection and prevention systems that monitor traffic from endpoints
  • Snort IDS (rule-based detection)
  • Suricata IDS/IPS (high-performance detection)

Aggregation Layer

Log collection and processing pipeline for normalizing and enriching security events
  • Logstash/Fluentd (log aggregation)
  • Elasticsearch (event storage and search)

Monitoring Layer

Infrastructure and application monitoring for availability, performance, and metrics
  • Zabbix (infrastructure monitoring)
  • Prometheus (metrics and alerts)

Security Platform

Unified security platform for visualization, correlation, and endpoint protection
  • Wazuh (SIEM/XDR capabilities)

Incident Management

Security incident tracking, investigation, and case management
  • TheHive (incident response platform)

Orchestration Layer

Automated response and infrastructure management
  • Cortex (SOAR)
  • Terraform/PyInfra (Infrastructure as Code)

​
Data Flow Architecture

The architecture implements three primary data flows that ensure comprehensive security visibility:
1

Network Security Flow

Endpoints → IDS (Snort/Suricata) → Logstash → Elasticsearch → WazuhNetwork traffic from endpoints is analyzed by intrusion detection systems. Detected events are sent to the log aggregation pipeline, stored in Elasticsearch, and visualized in Wazuh for correlation and analysis.
2

Infrastructure Monitoring Flow

Endpoints → Firewall → Zabbix → Prometheus → WazuhInfrastructure health and performance metrics flow through monitoring systems. Zabbix tracks availability and performance, Prometheus provides real-time metrics and alerting, and all data is integrated into Wazuh for unified visibility.
3

Incident Response Flow

Wazuh → TheHive → CortexSecurity events identified in Wazuh trigger incident tickets in TheHive. Cortex orchestrates automated response actions based on predefined playbooks, enabling rapid containment and remediation.
4

Future Integration Flow

Honeypots/VPN → Logstash/Wazuh (Long-term plan)Planned integration of deception technology and secure remote access with the core security platform.

​
Layer Deep Dive

​
Detection Layer: IDS/IPS

The first line of defense monitors network traffic for malicious activity:
Snort provides lightweight, signature-based intrusion detection. It uses a comprehensive rule set to identify known attack patterns and suspicious network behavior.Key Capabilities:
  • Real-time traffic analysis
  • Protocol analysis
  • Content searching/matching
  • Packet logging
Suricata offers advanced detection capabilities with multi-threading support for high-performance environments.Key Capabilities:
  • Multi-threaded processing
  • IDS and IPS modes
  • File extraction and analysis
  • Lua scripting support
  • TLS/SSL inspection

​
Aggregation and Storage

Centralized log collection and storage enable correlation and forensic analysis:
Logstash/Fluentd act as the data pipeline, ingesting logs from multiple sources, parsing and normalizing data, and enriching events with additional context before forwarding to storage.
Elasticsearch provides the scalable storage backend with powerful search and analytics capabilities, enabling rapid queries across millions of security events.

​
Infrastructure Monitoring

Comprehensive monitoring ensures security events are correlated with infrastructure health:
  • Zabbix: Monitors server availability, resource utilization, and application performance. Provides alerting for infrastructure anomalies that may indicate security issues.
  • Prometheus: Collects time-series metrics with a flexible query language, enabling real-time alerting and integration with visualization tools.

​
Central Security Platform: Wazuh

Wazuh serves as the unified security platform, providing:

Event Visualization

Customizable dashboards for real-time security event monitoring

Event Correlation

Intelligent correlation rules to detect complex attack patterns

EDR Capabilities

Endpoint detection and response for host-based security

Compliance Reporting

Built-in compliance frameworks and reporting

​
Incident Management and Orchestration

The incident response layer enables efficient security operations:
TheHive provides collaborative incident management with case tracking, task assignment, and investigation workflows. Security analysts can document findings, share intelligence, and track incident resolution.
Cortex automates repetitive security tasks through analyzers and responders. It can automatically enrich indicators, execute response actions, and integrate with external threat intelligence sources.
Infrastructure as Code tools enable automated deployment, configuration management, and response actions at the infrastructure level, ensuring consistent and repeatable security controls.

​
Long-Term Planned Components

The following components are planned for future implementation and are shown in yellow in the architecture diagram:
These components represent the long-term vision and are subject to evaluation before implementation.

Honeypots-Proxmox

Virtualized deception technology to attract attackers and gather intelligence on tactics and techniques

OPNsense Firewall

Open-source perimeter firewall for network segmentation, traffic filtering, and additional intrusion prevention

Tailscale VPN

Mesh VPN solution for secure remote access to the SOC infrastructure and management interfaces

​
Integration Points

The architecture emphasizes seamless integration between components:
  • Bidirectional data flow between monitoring and security platforms
  • Standardized log formats for consistent parsing and correlation
  • API-based integration for automated orchestration
  • Centralized authentication (where applicable)
  • Unified alerting through the Wazuh platform
The modular design allows components to be deployed incrementally, starting with core detection and monitoring capabilities and expanding to advanced orchestration and automation.

​
Scalability Considerations

The architecture is designed to scale across multiple dimensions:
  • Horizontal scaling: Add more IDS sensors, log processors, and storage nodes
  • Vertical scaling: Increase resources for compute-intensive components like Elasticsearch
  • Geographic distribution: Deploy regional sensors with centralized management
  • Data retention: Configure tiered storage for cost-effective long-term retention

​
Next Steps

To understand the design philosophy behind this architecture, continue to the Design Principles section. For detailed information about specific components, explore the Components section of the documentation.
