Headscale supports subnet routing and exit nodes, allowing you to access devices not running Tailscale and route internet traffic through specific nodes.

​
Subnet Routing

Subnet routing lets you access an entire network through a single Tailscale-connected node. For example, access your home network (192.168.1.0/24) from anywhere.

​
Setting Up a Subnet Router

1

Enable IP forwarding on the router node

echo 'net.ipv4.ip_forward = 1' | sudo tee -a /etc/sysctl.conf
echo 'net.ipv6.conf.all.forwarding = 1' | sudo tee -a /etc/sysctl.conf
sudo sysctl -p
2

Advertise routes when connecting

sudo tailscale up \
  --login-server http://localhost:8000 \
  --advertise-routes=192.168.1.0/24,192.168.3.0/24 \
  --authkey YOUR_PREAUTH_KEY
You can advertise multiple subnets by separating them with commas.
3

View advertised routes

docker exec headscale headscale routes list
Output:
ID | Node          | Prefix           | Advertised | Enabled | Primary
1  | home-router   | 192.168.1.0/24  | true       | false   | -
2  | home-router   | 192.168.3.0/24  | true       | false   | -
4

Enable the routes

docker exec headscale headscale routes enable --route-id 1
docker exec headscale headscale routes enable --route-id 2

​
Configure Firewall (Linux)

For the subnet router to work, configure the firewall:
# Allow forwarding on tailscale interface
sudo iptables -A FORWARD -i tailscale0 -j ACCEPT
sudo iptables -A FORWARD -o tailscale0 -j ACCEPT

# Save rules (Ubuntu/Debian)
sudo netfilter-persistent save

​
Using Subnet Routes

On client devices, accept routes:
sudo tailscale up \
  --login-server http://localhost:8000 \
  --accept-routes \
  --authkey YOUR_KEY
Now you can access devices on the advertised networks:
# Ping device on subnet
ping 192.168.1.100

# SSH to device on subnet
ssh [email protected]

# Access web interface
curl http://192.168.1.1

​
Auto-Approval of Routes

Automate route approval using ACL policies in config/policy.json:
config/policy.json
{
  "tagOwners": {
    "tag:servers": ["group:admins"]
  },
  "autoApprovers": {
    "routes": {
      "192.168.0.0/16": ["tag:servers"],
      "10.0.0.0/8": ["tag:servers"]
    }
  }
}
Create pre-auth keys with the tag:
docker exec headscale headscale preauthkeys create \
  --user myuser \
  --reusable \
  --expiration 24h \
  --tags tag:servers
Routes advertised by nodes with tag:servers will be automatically approved.

​
Exit Nodes

Exit nodes route all your internet traffic through a specific node in your network.

​
Setting Up an Exit Node

1

Enable IP forwarding

sudo sysctl -w net.ipv4.ip_forward=1
sudo sysctl -w net.ipv6.conf.all.forwarding=1
2

Configure NAT (Network Address Translation)

# Replace eth0 with your internet-facing interface
sudo iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE

# Save rules
sudo netfilter-persistent save
3

Advertise as exit node

sudo tailscale up \
  --login-server http://localhost:8000 \
  --advertise-exit-node \
  --authkey YOUR_PREAUTH_KEY
4

Approve the exit node

  1. Open http://localhost:3001/admin/
  2. Go to Routes page
  3. Find the exit node route (0.0.0.0/0 or ::/0)
  4. Click Approve

​
Using an Exit Node

On a client device:
tailscale exit-node list

​
Exit Node Use Cases

Secure Public WiFi

Route traffic through your home network when using untrusted public WiFi.

Access Region-Specific Content

Route traffic through a node in a different geographic location.

Bypass Network Restrictions

Access services blocked on your current network.

Privacy Protection

Hide your IP address from websites you visit.

​
Combining Exit Node and Subnet Routes

sudo tailscale up \
  --login-server http://localhost:8000 \
  --advertise-exit-node \
  --advertise-routes=192.168.1.0/24 \
  --authkey YOUR_KEY
This node serves as both:
  • An exit node for internet traffic
  • A subnet router for local network access

​
Auto-Approval for Exit Nodes

config/policy.json
{
  "tagOwners": {
    "tag:servers": ["group:admins"]
  },
  "autoApprovers": {
    "exitNode": ["tag:servers", "tag:personal"]
  }
}
Exit nodes with these tags will be automatically approved.

​
Advanced Routing Scenarios

​
Multiple Subnet Routers

Advertise different subnets from different nodes:
# Home router
sudo tailscale up \
  --login-server http://localhost:8000 \
  --advertise-routes=192.168.1.0/24 \
  --authkey YOUR_KEY

# Office router
sudo tailscale up \
  --login-server http://localhost:8000 \
  --advertise-routes=10.0.1.0/24 \
  --authkey YOUR_KEY

​
Route-Specific Access Control

Control which devices can access specific routes:
config/policy.json
{
  "acls": [
    {
      "action": "accept",
      "src": ["tag:personal"],
      "dst": ["192.168.1.0/24:*"],
      "comment": "Personal devices can access home network"
    },
    {
      "action": "accept",
      "src": ["tag:work"],
      "dst": ["10.0.1.0/24:*"],
      "comment": "Work devices can access office network"
    }
  ]
}

​
Docker Container as Subnet Router

docker-compose.yml
services:
  tailscale-router:
    image: tailscale/tailscale:latest
    hostname: docker-router
    environment:
      - TS_AUTHKEY=YOUR_KEY
      - TS_LOGIN_SERVER=http://host.docker.internal:8000
      - TS_ROUTES=192.168.1.0/24
      - TS_STATE_DIR=/var/lib/tailscale
    volumes:
      - tailscale-router:/var/lib/tailscale
      - /dev/net/tun:/dev/net/tun
    cap_add:
      - NET_ADMIN
      - SYS_MODULE
    sysctls:
      - net.ipv4.ip_forward=1
      - net.ipv6.conf.all.forwarding=1
    restart: unless-stopped

volumes:
  tailscale-router:

​
Monitoring Routes

​
List All Routes

docker exec headscale headscale routes list

​
Using Headplane GUI

  1. Open http://localhost:3001/admin/
  2. Go to Routes page
  3. View:
    • All advertised routes
    • Which routes are enabled
    • Which node advertises each route
    • Route IDs for management

​
Check Route Status on Device

# View accepted routes
tailscale status --peers

# Check routing table
ip route | grep tailscale

# Test connectivity
ping 192.168.1.1
traceroute 192.168.1.100

​
Troubleshooting

​
Subnet Route Not Working

1

Verify IP forwarding is enabled

cat /proc/sys/net/ipv4/ip_forward
# Should return: 1
2

Check route is enabled

docker exec headscale headscale routes list
# Verify "Enabled" column shows "true"
3

Verify firewall allows forwarding

sudo iptables -L FORWARD -v
# Should show ACCEPT rules for tailscale0
4

Check client accepts routes

tailscale status
# Should show "accept-routes: true"

​
Exit Node Not Working

1

Verify NAT is configured

sudo iptables -t nat -L POSTROUTING -v
# Should show MASQUERADE rule
2

Test internet connectivity on exit node

ping 8.8.8.8
curl https://ifconfig.me
3

Check exit node is advertised and approved

docker exec headscale headscale routes list
# Look for 0.0.0.0/0 route with Enabled: true
4

Verify client is using exit node

tailscale status
# Should show "exit node: <node-name>"

# Check your public IP
curl https://ifconfig.me
# Should match exit node's public IP

​
Route Conflicts

Error: Route overlaps with existing route Solution: Be specific with your subnet masks:
# Instead of advertising entire 192.168.0.0/16
# Advertise specific subnets
sudo tailscale up \
  --login-server http://localhost:8000 \
  --advertise-routes=192.168.1.0/24 \
  --authkey YOUR_KEY

​
Best Practices

Use Specific Subnets

Advertise only the specific networks you need:
--advertise-routes=192.168.1.0/24
Instead of broad ranges like 192.168.0.0/16

Tag Routers

Apply tags to subnet routers and exit nodes:
--tags tag:servers,tag:router
Use with ACL auto-approval

Monitor Route Usage

Regularly check which routes are active:
docker exec headscale headscale routes list

Document Your Network

Keep a record of:
  • Which nodes advertise which routes
  • Subnet ranges and their purposes
  • Exit node locations and capabilities

​
