Tree Structure & Structural Sharing

Overview

RotorTree uses a sophisticated chunked storage system with structural sharing to enable efficient snapshots and memory management. This design allows lock-free concurrent reads while minimizing memory allocation overhead.

The Problem

Naive Merkle tree implementations face challenges:

Snapshots are expensive: Copying the entire tree for each snapshot is prohibitive
Memory overhead: Each tree node requires a separate allocation
Cache efficiency: Random access patterns hurt CPU cache performance
Concurrent access: Shared mutable state requires locking

RotorTree solves these problems with a three-tier chunked structure.

Three-Tier Architecture

┌─────────────────────────────────────────────────────────┐
│                    ChunkedLevel                         │
│                                                         │
│  ┌───────────────────────────────────────────────┐    │
│  │         Immutable Segments                     │    │
│  │  (Arc<[Chunk; CHUNKS_PER_SEGMENT]>)           │    │
│  │                                                │    │
│  │  ┌─────────┐  ┌─────────┐  ┌─────────┐       │    │
│  │  │ Segment │  │ Segment │  │ Segment │  ...  │    │
│  │  │    0    │  │    1    │  │    2    │       │    │
│  │  └─────────┘  └─────────┘  └─────────┘       │    │
│  │     256          256          256              │    │
│  │    chunks       chunks       chunks            │    │
│  └───────────────────────────────────────────────┘    │
│                                                         │
│  ┌───────────────────────────────────────────────┐    │
│  │         Pending Chunks                         │    │
│  │  (Vec<Chunk>)                                  │    │
│  │                                                │    │
│  │  ┌───────┐  ┌───────┐  ┌───────┐             │    │
│  │  │ Chunk │  │ Chunk │  │ Chunk │  ...        │    │
│  │  └───────┘  └───────┘  └───────┘             │    │
│  │     128        128        128                  │    │
│  │    hashes     hashes     hashes                │    │
│  │                                                │    │
│  │  (max CHUNKS_PER_SEGMENT - 1 = 255)           │    │
│  └───────────────────────────────────────────────┘    │
│                                                         │
│  ┌───────────────────────────────────────────────┐    │
│  │         Tail Buffer                            │    │
│  │  ([Hash; CHUNK_SIZE])                          │    │
│  │                                                │    │
│  │  [H₀][H₁][H₂][H₃]...[H₁₂₇]                    │    │
│  │   ↑                    ↑                       │    │
│  │   filled           tail_len                    │    │
│  └───────────────────────────────────────────────┘    │
└─────────────────────────────────────────────────────────┘

Tier 1: Tail Buffer

A fixed-size mutable array for recently inserted hashes. Source: src/tree.rs:170

tail: [Hash; CHUNK_SIZE],   // Fixed-size array (128 hashes)
tail_len: usize,             // Number of valid entries

Capacity: CHUNK_SIZE (default: 128 hashes = 4 KB)
Behavior: Fills from left to right
Promotion: When full, promoted to a Chunk in the pending buffer

Tier 2: Pending Chunks

A growable vector of committed chunks not yet frozen into a segment. Source: src/tree.rs:167

pending: Vec<Chunk>,  // At most CHUNKS_PER_SEGMENT - 1 items

Capacity: Up to CHUNKS_PER_SEGMENT - 1 (default: 255 chunks)
Behavior: Grows as tail buffers are promoted
Freezing: When full, all chunks are frozen into an immutable segment

Tier 3: Immutable Segments

Arc-shared arrays of frozen chunks, never modified after creation. Source: src/tree.rs:165

segments: Vec<Arc<[Chunk; CHUNKS_PER_SEGMENT]>>,

Size: Each segment contains exactly CHUNKS_PER_SEGMENT (default: 256) chunks
Sharing: Multiple snapshots can share the same segments via Arc
Immutability: Once created, never modified (copy-on-write if needed)

Chunks: The Core Unit

A Chunk is an Arc-wrapped array of hashes, enabling structural sharing.

Without Storage Feature

Source: src/tree.rs:42-66

struct Chunk(Arc<[Hash; CHUNK_SIZE]>);

impl Chunk {
    fn as_slice(&self) -> &[Hash; CHUNK_SIZE] {
        &self.0
    }

    fn make_mut(&mut self) -> &mut [Hash; CHUNK_SIZE] {
        Arc::make_mut(&mut self.0)  // Copy-on-write if refcount > 1
    }

    fn new_memory(data: [Hash; CHUNK_SIZE]) -> Self {
        Self(Arc::new(data))
    }
}

Memory footprint: 128 hashes × 32 bytes = 4,096 bytes per chunk
Arc overhead: 8 bytes (pointer) per reference
Copy-on-write: Arc::make_mut() clones only if shared

With Storage Feature

Source: src/tree.rs:68-132 With the storage feature, chunks can be backed by memory-mapped files:

enum ChunkInner {
    Memory(Arc<[Hash; CHUNK_SIZE]>),
    Mapped {
        region: Arc<MmapRegion>,
        offset: usize,
    },
}

Memory chunks: Allocated in RAM, same as without storage
Mapped chunks: Read directly from mmap’d data files
Transparent access: Same as_slice() interface for both
COW on write: Mapped chunks copy to memory if modified

Constants

From src/tree.rs:21-28:

pub(crate) const CHUNK_SIZE: usize = 128;
const CHUNKS_PER_SEGMENT: usize = 256;

Constant	Value	Rationale
`CHUNK_SIZE`	128	128 × 32 bytes = 4 KB (typical page size)
`CHUNKS_PER_SEGMENT`	256	256 × 4 KB = 1 MB segment granularity

These values balance:

Cache efficiency: 4 KB chunks fit in L1/L2 cache
Arc granularity: 1 MB segments reduce Arc overhead
Snapshot cost: Small enough for cheap clones

ChunkedLevel Operations

Reading: `get()` and `get_group()`

Source: src/tree.rs:214-249

fn get(&self, index: usize) -> Result<Hash, TreeError> {
    let chunk_idx = index / CHUNK_SIZE;
    let offset = index % CHUNK_SIZE;

    if chunk_idx < self.chunk_count() {
        Ok(self.chunk_slice(chunk_idx)[offset])
    } else {
        Ok(self.tail[offset])
    }
}

fn get_group(&self, start: usize, count: usize, out: &mut [Hash]) {
    let chunk_idx = start / CHUNK_SIZE;
    let offset = start % CHUNK_SIZE;

    if offset + count <= CHUNK_SIZE {
        // Fast path: entire group in one chunk
        let src = if chunk_idx < self.chunk_count() {
            &self.chunk_slice(chunk_idx)[offset..offset + count]
        } else {
            &self.tail[offset..offset + count]
        };
        out[..count].copy_from_slice(src);
    } else {
        // Slow path: spans chunks
        for (i, item) in out.iter_mut().enumerate().take(count) {
            *item = self.get(start + i)?;
        }
    }
}

Fast path optimization: When a group of hashes fits entirely within a single chunk (common case), it’s a single slice copy.

Writing: `set()` and `extend()`

Source: src/tree.rs:252-343

fn set(&mut self, index: usize, value: Hash) -> Result<(), TreeError> {
    if self.len <= index {
        self.ensure_len(index + 1)?;
    }
    self.set_preallocated(index, value);
    Ok(())
}

fn extend(&mut self, values: &[Hash]) -> Result<(), TreeError> {
    // 1. Fill current tail
    if self.tail_len > 0 {
        let space = CHUNK_SIZE - self.tail_len;
        let to_copy = space.min(values.len());
        self.tail[self.tail_len..self.tail_len + to_copy]
            .copy_from_slice(&values[..to_copy]);
        self.tail_len += to_copy;
        if self.tail_len == CHUNK_SIZE {
            self.promote_tail();
        }
    }

    // 2. Create full chunks directly
    let full_chunks = remaining.len() / CHUNK_SIZE;
    for i in 0..full_chunks {
        let chunk: [Hash; CHUNK_SIZE] = remaining[i * CHUNK_SIZE..(i + 1) * CHUNK_SIZE]
            .try_into()?;
        self.push_chunk(Chunk::new_memory(chunk));
    }

    // 3. Copy remainder to tail
    if !remaining.is_empty() {
        self.tail[..remaining.len()].copy_from_slice(remaining);
        self.tail_len = remaining.len();
    }

    Ok(())
}

Efficiency: extend() bypasses the tail buffer for full chunks, creating them directly.

Promotion and Freezing

Source: src/tree.rs:382-407

fn promote_tail(&mut self) {
    debug_assert_eq!(self.tail_len, CHUNK_SIZE);
    self.push_chunk(Chunk::new_memory(self.tail));
    self.tail = [[0u8; 32]; CHUNK_SIZE];
    self.tail_len = 0;
}

fn push_chunk(&mut self, chunk: Chunk) {
    self.pending.push(chunk);
    if self.pending.len() == CHUNKS_PER_SEGMENT {
        self.freeze_pending();
    }
}

fn freeze_pending(&mut self) {
    debug_assert_eq!(self.pending.len(), CHUNKS_PER_SEGMENT);
    let pending = std::mem::take(&mut self.pending);
    let boxed_arr: Box<[Chunk; CHUNKS_PER_SEGMENT]> = pending
        .into_boxed_slice()
        .try_into()
        .unwrap();
    self.segments.push(Arc::from(boxed_arr));
}

Flow:

Tail fills up → promote to pending
Pending fills up → freeze to segment
Segment created → immutable forever

Snapshots

Source: src/tree.rs:674-686

fn snapshot(&self) -> TreeSnapshot<N, MAX_DEPTH> {
    let mut levels = core::array::from_fn(|_| ChunkedLevel::new());
    let snap_count = core::cmp::min(self.depth.saturating_add(1), MAX_DEPTH);

    for (dst, src) in levels.iter_mut().zip(self.levels.iter()).take(snap_count) {
        *dst = src.clone();  // Clone ChunkedLevel
    }

    TreeSnapshot {
        levels,
        root: self.root,
        size: self.size,
        depth: self.depth,
    }
}

What gets cloned?

Segments: Only the Arc is cloned (cheap pointer bump)
Pending chunks: Each Chunk is cloned (Arc pointer bump per chunk)
Tail buffer: Copied entirely (128 hashes = 4 KB)

Cost analysis: For a tree with 1M leaves (N=4, depth≈10):

Level 0: ~7,813 chunks
- Segments: ~30 segments × 8 bytes = 240 bytes
- Pending: ~0-255 chunks × 8 bytes ≈ 2 KB
- Tail: 4 KB
Levels 1-9: Similar but smaller

Total snapshot cost: ~50-100 KB of Arc pointer bumps + ~40 KB of tail copies

Copy-on-Write Semantics

Source: src/tree.rs:53-55 and src/tree.rs:96-105

fn make_mut(&mut self) -> &mut [Hash; CHUNK_SIZE] {
    if matches!(&self.0, ChunkInner::Mapped { .. }) {
        // Mapped chunk: always copy to memory
        let data = *self.as_slice();
        self.0 = ChunkInner::Memory(Arc::new(data));
    }

    match &mut self.0 {
        ChunkInner::Memory(arc) => Arc::make_mut(arc),  // COW if shared
        ChunkInner::Mapped { .. } => unreachable!(),
    }
}

Behavior:

If chunk is in a frozen segment (Arc refcount > 1), Arc::make_mut() clones it
If chunk is memory-mapped, always copies to RAM
Otherwise, returns mutable reference (no copy)

Memory Layout Example

For a tree with 100,000 leaves at level 0:

100,000 leaves = 781 chunks + 1 partial chunk

┌─────────────────────────────────────────────────┐
│ Segment 0: chunks 0-255                         │
│ (Arc shared with all snapshots)                 │
│ Size: 256 × 4 KB = 1 MB                         │
└─────────────────────────────────────────────────┘

┌─────────────────────────────────────────────────┐
│ Segment 1: chunks 256-511                       │
│ (Arc shared with all snapshots)                 │
│ Size: 256 × 4 KB = 1 MB                         │
└─────────────────────────────────────────────────┘

┌─────────────────────────────────────────────────┐
│ Segment 2: chunks 512-767                       │
│ (Arc shared with all snapshots)                 │
│ Size: 256 × 4 KB = 1 MB                         │
└─────────────────────────────────────────────────┘

┌─────────────────────────────────────────────────┐
│ Pending: chunks 768-780 (13 chunks)             │
│ (Arc per chunk, cloned on snapshot)             │
│ Size: 13 × 4 KB = 52 KB                         │
└─────────────────────────────────────────────────┘

┌─────────────────────────────────────────────────┐
│ Tail: 32 hashes (partial chunk 781)             │
│ (Copied on snapshot)                            │
│ Size: 32 × 32 bytes = 1 KB                      │
└─────────────────────────────────────────────────┘

Total memory:
- Actual data: 100,000 × 32 bytes ≈ 3.2 MB
- Overhead: Arc pointers + metadata ≈ 100 KB
- Snapshot cost: 3 Arc bumps + 13 Arc bumps + 1 KB copy ≈ 1.5 KB

Chunk Access Patterns

Sequential Scan

for i in 0..level.len() {
    let hash = level.get(i)?;
    // Process hash
}

Performance: Excellent cache locality within chunks (128 sequential hashes).

Group Access (Common in Tree Operations)

let group_start = parent_idx * N;
let mut children = [[0u8; 32]; N];
level.get_group(group_start, N, &mut children);
let parent = hasher.hash_children(&children);

Performance: Fast path when group doesn’t span chunk boundaries (common case).

Random Access

let hash = level.get(random_index)?;

Performance: Two-step lookup (chunk_idx, offset), but chunks are small enough to stay in cache.

Trade-offs

Chunk Size

Smaller chunks (e.g., 64):

✅ Cheaper snapshots (less tail to copy)
✅ Finer-grained Arc sharing
❌ More Arc overhead
❌ More segment allocations

Larger chunks (e.g., 256):

✅ Less Arc overhead
✅ Better sequential scan performance
❌ More expensive snapshots
❌ Wasted space for small trees

Choice: 128 balances these factors and matches CPU page size.

Segment Size

Smaller segments (e.g., 128 chunks):

✅ Faster freezing
❌ More Arc overhead per snapshot

Larger segments (e.g., 512 chunks):

✅ Fewer Arc bumps per snapshot
❌ Longer pending phase
❌ Larger allocation when freezing

Choice: 256 provides 1 MB segments, reasonable for most workloads.

Copy-on-Write Behavior

Aggressive COW (always clone on write to shared chunk):

✅ Protects all snapshots
❌ High memory usage with many snapshots

Lazy COW (only clone when necessary):

✅ Lower memory usage
❌ Complexity in tracking mutations

Choice: Rust’s Arc::make_mut() provides automatic lazy COW.

From src/tree.rs:1122-1136:

#[test]
fn chunked_level_clone_shares_arcs() {
    let mut level = ChunkedLevel::new();
    for i in 0..CHUNK_SIZE + 5 {
        level.push(leaf(i as u32)).unwrap();
    }
    let snap = level.clone();

    // The completed chunk Arc is shared
    assert!(Chunk::ptr_eq(level.get_chunk(0), snap.get_chunk(0)));

    // Data matches
    for i in 0..level.len() {
        assert_eq!(level.get(i).unwrap(), snap.get(i).unwrap());
    }
}

Get Started

Core Concepts

Guides

Advanced

Tree Structure & Structural Sharing

Overview

The Problem

Three-Tier Architecture

Tier 1: Tail Buffer

Tier 2: Pending Chunks

Tier 3: Immutable Segments

Chunks: The Core Unit

Without Storage Feature

With Storage Feature

Constants

ChunkedLevel Operations

Reading: `get()` and `get_group()`

Writing: `set()` and `extend()`

Promotion and Freezing

Snapshots

Copy-on-Write Semantics

Memory Layout Example

Chunk Access Patterns

Sequential Scan

Group Access (Common in Tree Operations)

Random Access

Trade-offs

Next Steps

Storage Modes

Memory Management

Build docs developers (and LLMs) love

Get Started

Core Concepts

Guides

Advanced

​Overview

​The Problem

​Three-Tier Architecture

​Tier 1: Tail Buffer

​Tier 2: Pending Chunks

​Tier 3: Immutable Segments

​Chunks: The Core Unit

​Without Storage Feature

​With Storage Feature

​Constants

​ChunkedLevel Operations

​Reading: get() and get_group()

​Writing: set() and extend()

​Promotion and Freezing

​Structural Sharing

​Snapshots

​Copy-on-Write Semantics

​Memory Layout Example

​Chunk Access Patterns

​Sequential Scan

​Group Access (Common in Tree Operations)

​Random Access

​Trade-offs

​Testing Structural Sharing

​Next Steps

Storage Modes

Memory Management

Build docs developers (and LLMs) love

Overview

The Problem

Three-Tier Architecture

Tier 1: Tail Buffer

Tier 2: Pending Chunks

Tier 3: Immutable Segments

Chunks: The Core Unit

Without Storage Feature

With Storage Feature

Constants

ChunkedLevel Operations

Reading: `get()` and `get_group()`

Writing: `set()` and `extend()`

Promotion and Freezing

Structural Sharing

Snapshots

Copy-on-Write Semantics

Memory Layout Example

Chunk Access Patterns

Sequential Scan

Group Access (Common in Tree Operations)

Random Access

Trade-offs

Testing Structural Sharing

Next Steps
