The <Editor> component provides a form-based UI for editing task properties. It connects to the Gantt through a shared API instance, reads the currently selected task from the store, and dispatches update-task and delete-task actions when the user makes changes.

​
Wiring up the Editor

The minimum setup requires two things: exposing the Gantt API via the init prop and passing that API to <Editor>.
GanttWithEditor.jsx
import { useState } from 'react';
import { Gantt, Editor } from '@svar-ui/react-gantt';
import '@svar-ui/react-gantt/all.css';

export default function App() {
  const [api, setApi] = useState();

  return (
    <>
      <Gantt
        init={setApi}
        tasks={tasks}
        links={links}
        scales={scales}
      />
      {api && <Editor api={api} />}
    </>
  );
}
Render <Editor> conditionally ({api && <Editor api={api} />}) so it only mounts after the Gantt has initialised and the API is available.
Double-clicking a task bar or a grid row opens the editor automatically. You can also open it programmatically:
api.exec('show-editor', { id: taskId });
To open the editor automatically after every add-task action (so newly created tasks are immediately editable), listen to the event inside init:
const init = useCallback((ganttApi) => {
  setApi(ganttApi);
  ganttApi.on('add-task', ({ id }) => {
    ganttApi.exec('show-editor', { id });
  });
}, []);

// ...
<Gantt init={init} ... />
The placement prop on <Editor> controls where the form appears. The default is 'sidebar', which renders it as a panel alongside the chart. Use 'modal' to display it as an overlay dialog.

​
Configuring editor fields

By default the editor shows all standard fields (name, type, start, end, duration, progress, details, links). Use getEditorItems() to retrieve those defaults and customise them.

​
Selecting a subset of fields

import { Editor, getEditorItems } from '@svar-ui/react-gantt';
import { useMemo } from 'react';

const keys = ['text', 'type', 'start', 'end', 'duration', 'progress', 'details'];
const defaultEditorItems = getEditorItems();

const items = useMemo(
  () => keys.map((key) => ({ ...defaultEditorItems.find((op) => op.key === key) })),
  [],
);

// ...
<Editor api={api} items={items} />

​
Adding a custom field

Each item in the items array is a field descriptor with at least a key, a comp (the registered editor control type), and a label.
const items = [
  ...getEditorItems(),
  {
    key: 'priority',
    comp: 'select',
    label: 'Priority',
    options: [
      { id: 'low',    label: 'Low' },
      { id: 'normal', label: 'Normal' },
      { id: 'high',   label: 'High' },
    ],
  },
];
Built-in comp types are: text, date, counter, slider, twostate, select, links.

​
Registering custom editor controls

registerEditorItem(name, Component) maps a string key to any React component, making it available as a comp type in field descriptors. Call it once at module level (or inside a useEffect with an empty dependency array).
@svar-ui/react-core is automatically installed as a dependency of @svar-ui/react-gantt. You do not need to add it to your package.json separately.
import { useEffect } from 'react';
import { Gantt, Editor, registerEditorItem, getEditorItems } from '@svar-ui/react-gantt';
import { RadioButtonGroup } from '@svar-ui/react-core';
import UserCombo from './UserCombo';

// Register once — safe to call before the component tree renders.
useEffect(() => {
  registerEditorItem('radio', RadioButtonGroup);
  registerEditorItem('user-combo', UserCombo);
}, []);

const items = useMemo(() => {
  const base = getEditorItems();
  // Replace the built-in type selector with radio buttons.
  const idx = base.findIndex((d) => d.key === 'type');
  base.splice(idx, 1, {
    key: 'type',
    comp: 'radio',
    label: 'Type',
    options: [{ value: 'task', label: 'Task' }, { value: 'milestone', label: 'Milestone' }],
    config: { type: 'inline' },
  });

  // Add a custom assigned-to combo.
  base.push({
    key: 'assigned',
    comp: 'user-combo',
    label: 'Assigned',
    options: users,
  });

  return base;
}, []);

​
Validation

Add required and validation / validationMessage to any field descriptor. Validation runs on every change when autoSave is true, and on save when autoSave is false.
const items = useMemo(
  () =>
    getEditorItems().map((ed) => ({
      ...ed,
      // Task name is required.
      ...(ed.comp === 'text' && { required: true }),
      // Duration must not exceed 50 days.
      ...(ed.comp === 'counter' && {
        validation: (v) => v <= 50,
        validationMessage: 'Task duration should not exceed 50 days',
      }),
    })),
  [],
);

// Pass autoSave={false} so invalid forms are never saved mid-edit.
<Editor api={api} items={items} autoSave={false} />
When autoSave={true} (the default), a field with a failing validation function will silently block saves for that field only. Set autoSave={false} if you need full-form validation with error messages before any data is written.

​
Read-only mode

You can make either the whole Gantt or just the Editor read-only.
// Disables all drag, resize, inline editing, and context menu write actions.
<Gantt readonly={true} tasks={tasks} scales={scales} />

​
Hotkeys

The Gantt chart registers keyboard shortcuts globally while the chart is in focus. None of the hotkeys fire when the cursor is inside an <input> or <textarea>.
HotkeyAction
DeleteDelete the selected task(s)
TabIndent the selected task (make it a child of the task above)
Shift+TabOutdent the selected task
Ctrl+ZUndo (requires undo={true} on <Gantt>)
Ctrl+YRedo (requires undo={true} on <Gantt>)
The Editor additionally supports Ctrl+Z / Ctrl+Y for undo/redo when the undo prop is enabled on <Gantt>. These are registered via the hotkeys prop on <Editor>:
// The Editor wires Ctrl+Z / Ctrl+Y automatically when undo is enabled.
// Pass extra hotkeys via the hotkeys prop:
<Editor
  api={api}
  hotkeys={{
    'ctrl+s': (ev) => {
      ev.preventDefault();
      api.exec('update-task', { id: activeTaskId, task: currentValues });
    },
  }}
/>
Hotkeys are processed in last-registered-first order. Returning early from a handler prevents lower-priority handlers from firing. Hotkeys do not fire while focus is inside an <input> or <textarea>.

​
Editor props reference

PropTypeDefaultDescription
apiIApi—Required. The API instance obtained from <Gantt init={...}>.
itemsarray[]Custom field list. Falls back to getEditorItems() defaults when empty.
placement'sidebar' | 'modal''sidebar'Where the editor renders.
layoutstring'default'Layout variant for the editor panel.
autoSavebooleantrueWhen true, saves each field change immediately.
readonlybooleanfalseRenders field values as plain text; hides the Delete button.
topBarboolean | objecttrueTop bar config. false hides it; an object overrides buttons.
bottomBarboolean | objecttrueBottom bar config.
focusbooleanfalseAuto-focuses the first editable field on open.
hotkeysobject{}Additional hotkey handlers merged with the built-in undo/redo bindings.
