Prerequisites

Before building the Android app, ensure you have the following installed:
  • Node.js (v16 or higher)
  • Android Studio (latest stable version)
  • Java Development Kit (JDK) 17 or higher
  • Android SDK with the following components:
    • Android SDK Platform 35 (API Level 35)
    • Android SDK Build-Tools
    • Android SDK Command-line Tools

​
Environment Setup

1

Install Android Studio

Download and install Android Studio from the official website.
2

Configure Android SDK

Open Android Studio and navigate to Settings > Appearance & Behavior > System Settings > Android SDK.Install the following:
  • Android SDK Platform 35 (compileSdk version)
  • Android SDK Build-Tools 35.0.0 or higher
3

Set Environment Variables

Add the following to your shell profile (~/.bashrc, ~/.zshrc, etc.):
export ANDROID_HOME=$HOME/Android/Sdk
export PATH=$PATH:$ANDROID_HOME/emulator
export PATH=$PATH:$ANDROID_HOME/platform-tools
export PATH=$PATH:$ANDROID_HOME/cmdline-tools/latest/bin
Reload your shell configuration:
source ~/.bashrc  # or ~/.zshrc

​
Project Configuration

The Android app is configured with the following specifications:
PropertyValue
Application IDcom.ciclovital.app
Namespacecom.ciclovital.app
Min SDK Version23 (Android 6.0)
Target SDK Version35 (Android 15)
Compile SDK Version35
Version Code1
Version Name1.0

​
Gradle Configuration

The project uses the following key dependencies:
android/variables.gradle
minSdkVersion = 23
compileSdkVersion = 35
targetSdkVersion = 35
androidxAppCompatVersion = '1.7.0'
androidxCoreVersion = '1.15.0'
coreSplashScreenVersion = '1.0.1'

​
Building the Android App

1

Install Dependencies

First, install all Node.js dependencies:
npm install
2

Build the Web Assets

Build the React application that will be bundled into the Android app:
npm run build
This creates optimized production files in the dist directory, which Capacitor will use as the web runtime.
3

Sync Capacitor

Copy the web assets to the Android platform and update native dependencies:
npx cap sync android
This command:
  • Copies the built web app from dist to android/app/src/main/assets/public
  • Updates Capacitor plugins
  • Syncs configuration from capacitor.config.json
4

Open in Android Studio

Open the Android project in Android Studio:
npx cap open android
Alternatively, open the android directory directly in Android Studio.
5

Build and Run

In Android Studio:
  1. Wait for Gradle sync to complete
  2. Select a device or emulator from the device dropdown
  3. Click the Run button (green play icon) or press Shift + F10
Or build from the command line:
cd android
./gradlew assembleDebug
The APK will be generated at: android/app/build/outputs/apk/debug/app-debug.apk

​
Running on a Device

​
Using an Emulator

1

Create an AVD

In Android Studio, open Device Manager and create a new Android Virtual Device (AVD).Recommended configuration:
  • Device: Pixel 6 or similar
  • System Image: Android 15 (API 35) or Android 13 (API 33)
  • RAM: 2048 MB or higher
2

Launch the Emulator

Start the emulator from Device Manager, then run:
npx cap run android

​
Using a Physical Device

1

Enable Developer Options

On your Android device:
  1. Go to Settings > About Phone
  2. Tap Build Number 7 times to enable Developer Options
  3. Go back to Settings > System > Developer Options
  4. Enable USB Debugging
2

Connect and Verify

Connect your device via USB and verify it’s recognized:
adb devices
You should see your device listed. Accept the USB debugging prompt on your device.
3

Run the App

Deploy to your connected device:
npx cap run android

​
Development Workflow

For faster development iterations with live reload:
1

Start the Dev Server

Run the Vite development server:
npm run dev
The server will start on http://localhost:5173 (or another port if 5173 is busy).
2

Update Capacitor Config

Temporarily modify capacitor.config.json to point to your dev server:
{
  "appId": "com.ciclovital.app",
  "appName": "CicloVital",
  "webDir": "dist",
  "bundledWebRuntime": false,
  "server": {
    "url": "http://YOUR_LOCAL_IP:5173",
    "cleartext": true
  }
}
Replace YOUR_LOCAL_IP with your machine’s local IP address (e.g., 192.168.1.100).
3

Rebuild and Run

npx cap copy android
npx cap run android
The app will now load content from your dev server with hot reload support.
Remember to remove the server configuration from capacitor.config.json before building for production.

​
Building for Release

1

Generate a Signing Key

Create a keystore for signing your release APK:
keytool -genkey -v -keystore ciclovital-release.keystore \
  -alias ciclovital -keyalg RSA -keysize 2048 -validity 10000
Store the keystore file and password securely.
2

Configure Signing

Create android/app/signing.properties:
storeFile=/path/to/ciclovital-release.keystore
storePassword=YOUR_STORE_PASSWORD
keyAlias=ciclovital
keyPassword=YOUR_KEY_PASSWORD
Add signing configuration to android/app/build.gradle:
android {
    signingConfigs {
        release {
            def props = new Properties()
            file("signing.properties").withInputStream { props.load(it) }
            storeFile file(props['storeFile'])
            storePassword props['storePassword']
            keyAlias props['keyAlias']
            keyPassword props['keyPassword']
        }
    }
    buildTypes {
        release {
            signingConfig signingConfigs.release
            minifyEnabled false
            proguardFiles getDefaultProguardFile('proguard-android.txt'), 'proguard-rules.pro'
        }
    }
}
3

Build Release APK

npm run build
npx cap sync android
cd android
./gradlew assembleRelease
The signed APK will be at: android/app/build/outputs/apk/release/app-release.apk

​
Troubleshooting

​
Gradle Build Failures

If Gradle fails to build:
cd android
./gradlew clean
./gradlew assembleDebug --stacktrace

​
SDK Version Mismatches

Ensure you have Android SDK 35 installed. Check in Android Studio: Settings > Appearance & Behavior > System Settings > Android SDK

​
ADB Device Not Found

If adb devices doesn’t show your device:
adb kill-server
adb start-server
adb devices

​
Port Already in Use

If the dev server port is busy:
npm run dev -- --port 3000
Then update the server.url in capacitor.config.json accordingly.

​
Next Steps

Capacitor Configuration

Learn about Capacitor plugins and configuration
